BH805G

Size: 264.3mm*168.5mm*24mm

Material: ABS+PC

Fingerprint: Optical FAP30 fingerprint scanner

 ·Liveness finger detection (LFD) supported

 ·Platen Size (W*L) 21.0*27.0mm

 ·Sensing Area (W*L) 20.32*25.40mm

 ·Image Size: 400*500pixels

 ·Image Resolution 500dpi

 ·Gray Level 8bits, 256level

 ·Work Voltage 5.0V

 ·Work Current ≤150mA

 ·Operating Temperature -10°C~55°C

 ·Operating Humidity 10~93%R.H

 ·ESD Contact: ± 8KV, Air: ± 15KV

 ·Certifications: FCC, CE, RoHS, FIPS 201/PIV 071006, FBI Mobile ID FAP 30

 ·Fingerprint format: ISO19794-2, ISO19794-4, ANSI 378, ANSI 381 and WSQ supported

 ·OS support Windows 7/ 8/ 10/11, Android, Linux and other embedded systems

LCD: 8 inch, 1920*1200 IPS FHD 300LM

TP: 8 inch Capacitive, Scratch Resistant, G+G, Multi-Touch, Support Active Capacitor Stylus with Google 2.0 Protocol

OS: Android 14.0 with GMS

CPU: Octa Core, 2.4GHz, Arm Mali-G68 GPU

RAM: LP DDR4/4x/5, 6GB(Support 8GB/12GB)

Flash: UFS 3.1, 128GB(Support 256GB/512GB)

CAM: Front 8Mp(With AF&FF), Rear 24MP(With AF)

Battery: 3.8V/10000mah, removable battery

2G: GSM: B2/3/5/8, CDMA: B0/1

3G: WCDMA: B1/2/4/5/6/8/19

4G/5G: Optional

NFC: 13.56MHz ISO/IEC 1443 A/B, ISO/IEC 15693, ISO/IEC 18092, ST21 Chipset

RTC:  Support hardware RTC, less than 3seconds fault within 24hours

OTG: Support

Wi-Fi: 802.11a/b/c/g/n/ac/ax ,2.4GHz/5.0GHz, Dual band

Bluetooth: BT 5.2

GPS: GPS, BDS, GLONASS, GALILEO

FM: YES

Sensor: G-Sensor, Light Sensor, Gyroscope

MIC: 1*MIC

Speaker: Two stereo Speakers

Audio port: 3.5ø  earphones

USB Type-A: USB 2.0x1

Type-C: x1 (Data and Charging, 5V3A)

TF: TF Card x1 (UP TO 2T)

RJ45: RJ45 x1  (100M)

PSAM: 2x Standard PSAM

DC: Supply Power: 5V/3A 1xDC ø3.5mm

SIM card slot: Micro SIM x2

Key button: Power, Volume +, Volume -, reset

Quick button: Support

Status Indicator: 2 LED status indicators

Accessories:

1. Charger

    ·Input: 100-240V, 50/60hz, Output: 9V/2A

    ·Fast charging capability,

2. Type-C Cable

3. Carrying Bag Specialized rugged bag for tablet and accessories.

Software and SDK: Software development kit with manual for development and integration
